Glass polishing powders based on cerium oxide have long been established as the best polishing agents for all types of glass polishing applications.



Cerium oxide is unique in its polishing action because the cerium, while removing glass by abrasive action, reacts chemically with the glass surface to produce a brittle surface layer which is more readily removed than the glass itself. This results in rapid removal of the glass as well as producing a surface finish of outstanding quality.



For the most demanding applications, e. g. for the production of high quality optical components, a high cerium content and small particle size is required. For less demanding applications, e. g. for the edge polishing of flat glass, a higher particle size can be tolerated and consequently, lower cerium oxide content is acceptable.



Powders for the less demanding applications have a lower cerium content resulting in a lower price, but because the cerium is of a very high quality and the additives carefully selected to maintain high performance there is no loss of polishing performance when the powder is compared with powders which are more highly priced.



Weldon Chemicals Ltd produces a range of powders suitable for each different application in the glass polishing industry. We produce three products which are available from stock and can also produce powders to meet customers’ specifications. All our powders are based on chemically precipitated cerium with a very high purity.



This is very important to ensure the highest polishing performance. Many powders on the market are based on low grade cerium products and are therefore unable to give optimum performance expressed in terms of the cerium content.

Source: www.pixelio.de

Specifications of our products:



Cepol-S



Cepol-S is designed for the precision polishing of optical components. It finds application in the polishing of telescope lenses, TV camera lenses and other applications where the highest precision and surface quality are required.



The powder can also be used for the polishing of semiconductor wafers and other electronic components and a special grade with a particle size of less than 0.5 microns is available to special order where sub-micron precision is required.



D50:                                         1 micron

Cerium content:                         Ce O2   100%

Colour:                                     white

Polishing efficiency:                    30-60 mg/min/dm2

Recommended polishing lap:        Polyurethane

Recommended polishing speed:    not less than 500 rpm



No suspension agents are added so agitation of the slurry is recommended. Suspension agents can be recommended for particular applications.





Cepol-P



This powder is designed for optical components, ophthalmic lenses and camera lenses. The surface quality is exceptional for this type of powder. Because of the very high cerium content, polishing efficiency is very high and the small particle size ensures exceptional surface quality.



D50:                                         2 microns

Cerium content:                         Ce O2    80%

Colour:                                     light pink

Polishing efficiency:                   30-80 mg/min/dm2

Recommended polishing lap:       Polyurethane

Recommended polishing speed:   not less than 500 rpm



No suspension agents are added so agitation of the slurry is recommended. Suspension agents can be recommended for particular applications.

Source: www.pixelio.de

Cepol-G



Cepol-G is recommended for general polishing applications such as the polishing of flat glass, TV faceplates and ophthalmic lenses, where the maximum efficiency is required at the lowest possible cost. Surface quality is exceptionally good for this type of powder and it is recommended that this grade of powder is tried as an alternative to more expensive but slower polishing powders. It may thus be possible to achieve faster polishing rates with no sacrifice in surface finish.



D50:                                         4-6 microns

Cerium content:                         Ce O2    80%

Colour:                                     dark pink

Polishing efficiency:                    40-100 mg/min/dm2

Recommended polishing lap:        Felt or Polyurethane

Recommended polishing speed:    not less than 500 rpm



No suspension agents are added so agitation of the slurry is recommended. Suspension agents can be recommended for particular applications.

Please contact us to order your own copy of our detailed product brochure.
